The Vulcan V48G combines eight open burners with a full-size oven in a 48-inch footprint, making it a versatile centerpiece for restaurants, cafeterias, and institutional kitchens. The 240,000 BTU gas-fired design runs on natural gas and provides consistent heat across all cooking zones. The stainless steel front panel resists corrosion and simplifies daily cleaning, while the medium-duty construction balances durability with cost-effectiveness for operations with moderate volume demands.
Measuring 48 inches wide, 34 inches deep, and 37 inches tall, this floor model weighs 440 pounds and requires adequate clearance for gas line connection and ventilation. The integrated oven offers a working temperature range of 200–500 °F, suitable for baking, roasting, and holding tasks. One oven rack is included with the unit, and operators should plan for proper exhaust hood coverage over the entire cooking surface to meet local codes.
Installation requires a natural gas supply sized to deliver the full 240,000 BTU rating, along with appropriate shut-off valves and flexible connectors per local regulations. The V48G is covered by a 1-year parts warranty. Operators should verify that floor loading can support the 440-pound unit plus the weight of cookware and product, and ensure adequate aisle space around the 34-inch depth for safe access to burners and oven.
Metrics
| Width | 48 in |
|---|---|
| Depth | 34 in |
| Weight | 440 lb |
| Height | 37 in |
Descriptors
| Brand | Vulcan |
|---|---|
| Power Type | Gas |
| Duty Class | Medium |
| Form Factor | Floor |
| Capacity Class | Standard |
| Model Number | V48G |
| Dimensions | 48 × 34 × 37 in |
| Capacity | 8 burners + oven |
| Power Spec | 240000 BTU |
| Voltage / Phase | Natural gas |
| Construction | Stainless front |
| Temperature Range | 200–500 °F oven |
| Warranty Term | 1 year parts |
| Included Accessories | Oven rack |
Frequently asked questions
What are the BTU output and burner configuration of the Vulcan V48G?
The Vulcan V48G delivers 240,000 BTU total output across eight burners plus the oven. Published specifications confirm natural gas as the fuel type, with a temperature range of 200–500 °F in the oven compartment. Spec sheets list 48×34×37 in and 440 lb.
What are the exact dimensions and weight for installation planning?
The unit measures 48 inches wide, 34 inches deep, and 37 inches tall, with a shipping weight of 440 pounds. These dimensions should be used to plan floor space, clearances, and structural load requirements. Published figures put capacity at 8 burners + oven.
What warranty and accessories come with this range?
The Vulcan V48G includes a 1-year parts warranty and ships with one oven rack. Additional racks or other accessories would need to be sourced separately as needed for your operation.
